Series P5 PVC Shuttle Flow Switch
PVC Shuttle Flow Switch
The transparent Series P5 Shuttle Flow Switch features corrosion resistant, durable PVC housing for visual confirmation in flow/no flow applications. The switches have preset actuation points from 0.5 to 2.0 GPM for actuation on increasing flow. Switching is SPST NO no flow. Choose from 1/2˝ NPT or 3/4˝ IPS (for 0.5 GPM) or 1˝ IPS (for 2.0 GPM) inlet and outlet ports. The shuttle design has only one moving part for long life and minimum maintenance. Remove the one-piece bonnet and shuttle assembly to quickly clean the unit without disturbing the housing or piping. Rugged construction and excellent chemical compatibility simplify flow / no flow detection.
Base Model # | Description | Normally In Stock | Configure Part # |
P5-1 | PVC shuttle flow switch, actuation set point .5 GPM (1.89 LPM), 1/2" NPT port adapter. | Inquire | |
P5-2 | PVC shuttle flow switch, actuation set point .5 GPM (1.89 LPM), 3/4" IPS. | Inquire | |
P5-3 | PVC shuttle flow switch, actuation set point 2.0 GPM (7.57 LPM), 1" IPS. | Inquire |
